CUBICO High Contactor 30kW/AC3/65A/1NO+1NC Coil 24VAC
Article: LZDH65B0--
51 190 ₸
To order
The CUBICO High electromagnetic contactor is designed for switching asynchronous motors and other loads in alternating current networks. The device provides reliable control of high-power electrical circuits with rated power up to 30 kW at standard voltage 400V (AC-3).
Key technical parameters:
- Rated current: 65A
- Application category: AC-3 (asynchronous motors with soft start)
- Control voltage: 24V alternating current
- Contact configuration: 1 normally open (NO) + 1 normally closed (NC)
- Power loss: 55W
- Operating temperature range: from -25°C to +60°C
Dimensions and weight:
- Enclosure size: High (modular series)
- Width: 77 mm
- Height: 122.5 mm
- Depth: 118 mm
- Net weight: 1.2 kg
The contactor is designed for installation on DIN-rail in distribution cabinets and electrical panels. It is characterized by compactness and versatility for use in industrial control systems. EAN code: 9004840025439.
| EAN code | 9004840025439 |
|---|---|
| Net width | 77.00 mm |
| Net height | 122.50 mm |
| Net depth | 118.00 mm |
| Net weight | 1.20 kg |
| Power loss | 55.00 W |
| Min. ambient temperature | -25°C |
| Max. ambient temperature | 60°C |
| Size | High |
| Type | Contactor |
| AC coil voltage | 24V alternating current |
| Rated current | 65A |
| Rated power AC-3/400V | 30 kW |
| Packaging | 1 pcs., 20 pcs. |
