Load Switch 63A/3, MC1
Article: MC163034--
67 260 ₸
To order
MC1 63A/3 Load Switch — three-pole disconnector without remote control for industrial and distribution networks.
Purpose and application: Designed for switching and disconnection of electrical circuits with rated current up to 63A. Used as part of low-voltage distribution devices, control panels and electrical enclosures for safe disconnection of loaded circuits.
Design features:
- Three normally open contacts for three-phase systems
- Manual operation without remote control drives
- Compact design with dimensions 90×145 mm
- Without built-in overload protection (no trip mechanism)
Electrical parameters:
- Rated current: 63A
- Power loss: 6W at rated current
- Main contacts: 3 normally open contacts
Operating conditions:
- Operating temperature range: from -25°C to +60°C
- Weight: 0.93 kg
- Manufacturer: Schrack (Austrian electrical equipment manufacturer)
Package contents: 1 piece
| EAN Code | 9004840262216 |
|---|---|
| Net Width | 90.00 mm |
| Net Height | 145.00 mm |
| Net Weight | 0.93 kg |
| Power Loss | 6.00 W |
| Min. Ambient Temperature | -25°C |
| Max. Ambient Temperature | 60°C |
| Device Type | Load Disconnector without Remote Control |
| Rated Current | 63A |
| Size | 1 |
| Main Contacts | 3 normally open contacts |
| Trip Mechanism | without protection |
| Manufacturer | Schrack |
| Package Contents | 1 piece |
