RCCB C16A/1+N/6kA/30mA/A, AI 1M Series
Article: AI617516--
19 360 ₸
In stock
Residual Current Circuit Breaker (RCCB) designed to protect electrical circuits from leakage currents and overloads. The device provides reliable protection of people from electric shock and equipment from damage.
Key technical specifications:
- Rated current: 16 A
- Configuration: 1P+N (single-phase with neutral)
- Leakage trip current: 30 mA
- Trip type: A (sensitive to sinusoidal and pulsating leakage currents)
- Trip time: instantaneous (fast-acting)
- Trip characteristic: C (for protection of circuits with normal inrush currents)
- Switching capacity: 6 kA
- Standard: EN 61009-1
- Power loss: 4.5 W
Operating conditions:
- Ambient temperature range: from -25°C to +55°C
- Overall dimensions: 18 mm (width) × 88 mm (height) × 73.3 mm (depth)
- Weight: 140 g
- Installation: on standard profile DIN rail
The device is intended for installation in residential, commercial and industrial electrical distribution panels. Complies with European safety standards and provides selective protection of electrical circuits.
| EAN codes | 9004840872552, 9004840994902 |
|---|---|
| Net width | 18.00 mm |
| Net height | 88.00 mm |
| Net depth | 73.30 mm |
| Net weight | 0.14 kg |
| Power loss | 4.50 W |
| Min. ambient temperature | -25°C |
| Max. ambient temperature | 55°C |
| Standard | EN 61009-1 |
| Type | A (sensitive to pulsating current) |
| Type | Instantaneous |
| Characteristic | C |
| Rated current | 16 A |
| Pole | N+1 |
| Switching capacity | 6 kA |
| Series | AMPARO |
| Manufacturer | Schrack |
| Packaging | 1 pc., 110 pcs. |
