RCCB C25A/1+N/6kA/30mA/A, AI 1M Series
Article: AI617525--
19 360 ₸
In stock
RCCB (Residual Current Circuit Breaker) with a rated current of 25A designed to provide protection against leakage currents in single-phase circuits with neutral. The device simultaneously protects against overcurrent and earth leakage faults.
Key Specifications:
- Rated Current: 25A
- Configuration: 1+N (single-pole + neutral)
- Differential Current Operating Threshold: 30mA
- Operating Type: A (sensitive to pulsating DC and AC sinusoidal differential current)
- Tripping Characteristic: C (electromagnetic tripping at 5-10 times the rated current)
- Breaking Capacity: 6kA
- Response Speed: instantaneous disconnection
- Standard: EN 61009-1
- Series: AMPARO (AI 1M Series)
- Manufacturer: Schrack
Physical Dimensions and Parameters:
- Width: 18.00mm
- Height: 88.00mm
- Depth: 73.30mm
- Weight: 0.14kg
- Power Loss: 7.00W
Operating Conditions:
- Temperature Range: from -25°C to +55°C
Packaging: 1 piece or 110 pieces optional
| EAN codes | 9004840872576, 9004840995145 |
|---|---|
| Width (net) | 18.00mm |
| Height (net) | 88.00mm |
| Depth (net) | 73.30mm |
| Weight (net) | 0.14kg |
| Power Loss | 7.00W |
| Min. Ambient Temperature | -25°C |
| Max. Ambient Temperature | 55°C |
| Standard | EN 61009-1 |
| Type (current sensitivity) | A (sensitive to pulsating current) |
| Type (tripping) | Instantaneous |
| Characteristic | C |
| Rated Current | 25A |
| Poles | N+1 |
| Breaking Capacity | 6kA |
| Series | AMPARO |
| Manufacturer | Schrack |
| Packaging | 1 piece, 110 pieces |
