Four-Pole Automatic Circuit Breaker C50A/4, 6kA

Four-pole automatic circuit breaker with nominal current 50 A and breaking capacity 6 kA. Part of the AMPARO series manufactured by Schrack and complies with standards EN 60898-1:2019 and IEC 60898-1.

Main Parameters:

• Trip characteristic: C (for circuits with moderate inrush currents)
• Number of poles: 4
• Nominal current: 50 A
• Breaking capacity: 6 kA
• Type: AM6 (AC-MCB — alternating current automatic circuit breaker)

Operating Characteristics:

• Power loss: 23 W
• Ambient temperature range: -35°C to +70°C
• Weight: 0.41 kg
• Dimensions: 86 × 72 × 77 mm (L × W × H)
• EAN code: 9004840852028

The circuit breaker is designed to protect electrical circuits from overloads and short-circuit currents. Available in packages of 1, 3, or 45 pieces.
