Load disconnector designed for switching electrical circuits with a rated current of 63 A at voltages up to 660 V. Two-pole design allows simultaneous disconnection of both load poles.
Main characteristics:
- Rated current: 63 A
- Number of poles: 2
- Design type: Main load disconnector insulator
- Series: AMPARO
- Manufacturer: Schrack
- Power loss: 14 W
- Operating temperature range: from -25°C to +55°C
Dimensions and weight:
- Length: 75 mm
- Width: 36 mm
- Height: 77 mm
- Net weight: 0.17 kg
EAN code: 9004840023909
Packaging options: 1 pcs., 6 pcs., 90 pcs.
| EAN code | 9004840023909 |
|---|---|
| Length (net) | 75.00 mm |
| Width (net) | 36.00 mm |
| Height (net) | 77.00 mm |
| Weight (net) | 0.17 kg |
| Power loss | 14.00 W |
| Min. ambient temperature | -25°C |
| Max. ambient temperature | 55°C |
| Design | Main load disconnector insulator |
| Poles | 2 |
| Series | AMPARO |
| Current rating | 63 A |
| Manufacturer | Schrack |
| Packaging | 1 pcs., 6 pcs., 90 pcs. |
