End Cap for 3-Pole BSB-A Bus Bar 10 mm²
Article: BSB00115-A
250 ₸
In stock
End cap for 3-pole BSB-A assembled bus bar with cross-section of 10 mm². Designed for sealing and protecting the ends of busbar systems in electrical power distribution systems.
Technical Characteristics:
- Configuration: 3-pole
- Bus bar cross-section: 10 mm²
- Installation type: For high-current Neozed series circuit breakers (27 mm pitch)
- Operating temperature range: from -35°C to +70°C
Physical Parameters:
- Dimensions: 17 × 17 × 8 mm (W × H × D)
- Weight: 0.01 kg
- EAN code: 9004840993271
Supply:
Available in packaging of 1, 10, and 250 pieces.
Manufacturer: Schrack (Austria)
| EAN code | 9004840993271 |
|---|---|
| Net length | 8.00 mm |
| Net width | 17.00 mm |
| Net height | 17.00 mm |
| Net weight | 0.01 kg |
| Minimum ambient temperature | -35°C |
| Maximum ambient temperature | 70°C |
| Series | Accessories |
| Insert | Neozed high-current circuit breakers (27 mm pitch) |
| Design | Assembled bus bar |
| Poles | 3 |
| Cross-section | 10 mm² |
| Accessories | End cap |
| Manufacturer | Schrack |
| Packaging | 1 piece, 10 pieces, 250 pieces |
