Protective cover for terminals, 3-pole, for MC1
Article: MC190021--
7 800 ₸
To order
The protective cover is designed to seal and protect the terminals of 3-pole MC1 series contactors from dust, moisture, and mechanical damage. The cover provides reliable closure of terminal connections when the device is disconnected from the mains or during storage.
Technical specifications:
- Device type: Accessory for electrical equipment
- Number of poles: 3
- Compatibility: MC1 contactors
- Housing material: Plastic resistant to temperature effects
- Operating temperature range: -25°C to +60°C
- Overall dimensions: width 90 mm, height 88 mm
- Weight: 0.10 kg
- Manufacturer: Schrack
- EAN code: 9004840262636
- Packaging: 1 pcs or 15 pcs
| EAN code | 9004840262636 |
|---|---|
| Net width | 90.00 mm |
| Net height | 88.00 mm |
| Net weight | 0.10 kg |
| Min. ambient temperature | -25°C |
| Max. ambient temperature | 60°C |
| Device type | Accessories |
| Size | 1 |
| Accessories | Cover |
| Manufacturer | Schrack |
| Packaging | 1 pcs, 15 pcs |
