Independent Release 208-250V AC/DC for MC1, with 3m cable
Article: MC199744--
40 910 ₸
In stock
Independent release for MC1 series automatic disconnectors, designed for 208-250V AC/DC control voltage. The device is intended for remote disconnection of electrical circuits upon activation of external control signals.
Key specifications:
- Control voltage: 230V AC/DC
- Operating temperature range: -25°C to +60°C
- Power consumption: 0.10W (minimal load on control circuit)
- Cable length: 3 meters
- Weight: 0.04 kg
- Dimensions (L×W×H): 142×77×77 mm
- Compatibility: Working current release for MC1
- Manufacturer: Schrack
- EAN code: 9004840262490
The release is mounted directly on the disconnector and enables control of its operation via commands from external automation and protection devices. Classified as an accessory for low-voltage switching apparatus.
| EAN code | 9004840262490 |
|---|---|
| Net length | 142.00 mm |
| Net width | 77.00 mm |
| Net height | 77.00 mm |
| Net weight | 0.04 kg |
| Power loss | 0.10 W |
| Min. ambient temperature | -25°C |
| Max. ambient temperature | 60°C |
| Device type | Accessories |
| Size | 1 |
| AC control voltage | 230V AC, 230V DC |
| Accessories | Working current release |
| Manufacturer | Schrack |
| Packaging | 1 pc. |
