Gland plate for WSTVBF, 6 cable entries, IP65

The gland plate is designed for use with WSTVBF controllers and ensures organized cable entry into distribution systems.

Technical characteristics:

• Degree of protection: IP65 — complete protection against dust and high-pressure water jets
• Number of cable entries: 6 pcs.
• Operating temperature range: from -40°C to +130°C
• Dimensions: 216 × 84 × 35 mm (L×H×D)
• Net weight: 0.23 kg
• Colour: RAL 7035 (light grey)
• EAN code: 9004840852615

Supply includes:

• Plastic gland plate
• 4 plastic rivets for mounting

Purpose:

The panel is used for hermetic introduction of cables and wires into the enclosure, protecting internal components from moisture and contamination. Ideal for outdoor installations and humid environments due to the high IP65 degree of protection. Compact dimensions allow integration of the panel into standard WSTVBF mounting holes.

Conditions of use:

Suitable for operation in a wide temperature range, which allows its use in both cold and hot climatic conditions. Plastic construction provides chemical resistance and durability.
