Residual Current Circuit Breaker (RCCB) from Schrack's AI 1M series is designed to protect electrical circuits from leakage currents and overloads. The device provides reliable protection of people against electric shock when in contact with live conducting parts.
Technical Characteristics:
- Nominal Current: 6A
- Nominal Leakage Current (Trip Current): 30mA
- Breaking Capacity: 6kA
- Configuration: 1 Pole + Neutral (N+1)
- Trip Characteristic: B
- Trip Type: Instantaneous
- Sensitivity Type: A (Sensitive to AC and pulsating sinusoidal AC current)
- Compliance Standard: EN 61009-1
Physical Parameters:
- Width: 18.00 mm
- Height: 88.00 mm
- Depth: 73.30 mm
- Net Weight: 0.14 kg
- Power Dissipation: 2.50 W
Operating Conditions:
- Ambient Temperature Range: -25°C to +55°C
Packaging and Assembly:
Available in packs of 1 and 110 units. The modular design allows easy installation on standard DIN rail of 18 mm width.
The device is intended for use in electrical power distribution systems of residential, commercial, and industrial facilities.
| EAN Code | 9004840872606, 9004840995503 |
|---|---|
| Width (Net) | 18.00 mm |
| Height (Net) | 88.00 mm |
| Depth (Net) | 73.30 mm |
| Weight (Net) | 0.14 kg |
| Power Dissipation | 2.50 W |
| Min. Ambient Temperature | -25°C |
| Max. Ambient Temperature | 55°C |
| Standard | EN 61009-1 |
| Type | A (Sensitive to pulsating current) |
| Trip Type | Instantaneous |
| Characteristic | B |
| Current Rating | 6A |
| Pole | N+1 |
| Breaking Capacity | 6kA |
| Series | AMPARO |
| Manufacturer | Schrack |
| Packaging | 1 pcs., 110 pcs. |
