Three-phase busbar for 2×BE5, 45 mm, fork contact

Three-phase assembled busbar for electrical energy distribution systems, designed for installation in distribution devices with two BE5 modules. The busbar features a fork (pin-type) contact for reliable electrical connection.

Main parameters:

• Configuration: 3 phases for 2×BE5
• Busbar length: 45 mm
• Contact material: Copper, copper content 76.0 g
• Power loss at nominal current: 1.80 W
• Operating temperature range: from -25°C to +40°C

Physical dimensions:

• Width: 86.00 mm
• Height: 32.00 mm
• Depth: 13.00 mm

Technical characteristics:

The busbar ensures efficient distribution of three-phase current with minimal energy losses. The fork design provides reliable contact and simplicity of connection. The product is designed for stable operation across a wide range of ambient temperatures.

Package contents: 1 piece.

Manufacturer: Schrack
