Motor Protection Switch 0.16-0.25A/3 BE5
Article: BE500250--
22 490 ₸
To order
Motor protection switch designed to protect electric motors from overload and short-circuit conditions. The device ensures reliable circuit disconnection when nominal current is exceeded or emergency operating conditions occur.
Main Parameters:
- Current adjustment range: 0.16-0.25 A
- Short-circuit breaking capacity: 100 kA
- Power loss: 6 W
- Size: BE5 (installation on standard DIN rail)
- Operating temperature range: -25°C to +55°C
Physical dimensions:
- Width: 45 mm
- Height: 93 mm
- Depth: 76 mm
- Weight: 0.30 kg
The switch provides selective protection for low-power three-phase electric motors in industrial and commercial networks. Easily installed on standard DIN rails of distribution boards and control panels.
| EAN code | 9004840256154 |
|---|---|
| Net width | 45.00 mm |
| Net height | 93.00 mm |
| Net depth | 76.00 mm |
| Net weight | 0.30 kg |
| Power loss | 6.00 W |
| Min. ambient temperature | -25°C |
| Max. ambient temperature | 55°C |
| Current range | 0.16-0.25 A |
| Short-circuit breaking capacity | 100 kA |
| Type | Motor protection switch |
| Size | BE5 |
| Manufacturer | Schrack |
| Packaging | 1 pc., 70 pcs. |
