Motor Protection Switch 25-32A/3 BE5
Article: BE532000--
49 640 ₸
To order
Motor protection switch designed to protect electric motors from overloads and short circuits. The device provides reliable disconnection of the circuit when the set current is exceeded or an emergency situation occurs.
Main characteristics:
- Trip current range: 25–32 A
- Rated short-circuit capacity: 16 kA
- Power loss: 6 W
- Temperature range: from −25 °C to +55 °C
- Size: BE5 (standard DIN rail)
- Dimensions: width 45 mm, height 93 mm, depth 76 mm
- Weight: 0.30 kg
Manufacturer: Schrack
The device complies with three-phase motor protection requirements and can be installed on standard DIN rail in electrical cabinets.
| EAN code | 9004840495263 |
|---|---|
| Net width | 45.00 mm |
| Net height | 93.00 mm |
| Net depth | 76.00 mm |
| Net weight | 0.30 kg |
| Power loss | 6.00 W |
| Min. ambient temperature | −25 °C |
| Max. ambient temperature | 55 °C |
| Current range | 25.0–32.0 A |
| Rated short-circuit capacity | 16 kA |
| Type | Motor protection switch |
| Size | BE5 |
| Manufacturer | Schrack |
| Packaging | 1 pc., 70 pc. |
