Automatic circuit breaker with RCD B10A/1+N, 6kA, 30mA, type A

Combined automatic circuit breaker with integrated residual current device (RCD) from the AMPARO series. Designed to protect electrical circuits against overloads, short circuits, and earth leakage current.

Key characteristics:

• Rated current: B10A
• Configuration: 1+N (single pole + neutral)
• Breaking capacity: 6 kA
• Rated sensitivity IΔn: 30 mA
• Type A: sensitive to pulsating and DC components of leakage current — suitable for protecting circuits with electronic devices
• Trip characteristic: B (instantaneous disconnection when rated current is exceeded)
• Operating temperature range: -25°C to +60°C
• Power loss: 2.96 W

Compliance with standards:

The device is developed and certified in accordance with European and international standards: EN 61009-1:2012 + A1:2014 + A2:2014 + A11:2015 + A12:2016, EN 61009-2-1:1994 + A11:1998, IEC 61009-1, IEC 61009-2-1.

Application:

Used in distribution panels of residential, commercial, and industrial facilities to protect individual consumer groups from simultaneous exposure to overcurrent and earth leakage current. Combined design eliminates the need for separate circuit breaker and RCD installation, saving space in the panel.
