A residual current circuit breaker (RCCB) designed to protect electrical circuits from leakage currents and overloads. The device activates when the residual current exceeds the rated sensitivity threshold.
Key Parameters:
- Rated Current: 16A
- Rated Sensitivity: 30mA
- Switching Capacity: 10kA
- Disconnection Characteristic: C (instantaneous tripping on overcurrent)
- Tripping Type: A (sensitive to pulsating alternating and direct sinusoidal residual current)
- Number of Poles: 2 (1P+N)
- Series: BOLF
Technical Specifications:
- Dimensions: 76×35×80 mm
- Weight: 0.11 kg
- Power Loss: 6.10 W
- Operating Temperature Range: -35°C to +60°C
- Compliance Standards: EN 61009-1:2012 + A12:2006, EN 61009-2-1:1994 + A11:1998
- EAN Code: 9004840620054
Application: Used in single-phase and three-phase electrical networks to protect people from electric shock due to direct and indirect contact, as well as to protect against fire caused by leakage currents through insulation.
Packaging: 1 pcs., 60 pcs.
| EAN Code | 9004840620054 |
|---|---|
| Length | 76.00mm |
| Width | 35.00mm |
| Height | 80.00mm |
| Weight | 0.11kg |
| Power Loss | 6.10W |
| Min. Ambient Temperature | -35°C |
| Max. Ambient Temperature | 60°C |
| Standard | EN 61009-1:2012 + A12:2006, EN 61009-2-1:1994 + A11:1998 |
| Type | A (sensitive to pulsating current) |
| Type | instantaneous |
| Rated Sensitivity IΔn | 30mA |
| Characteristic | C |
| Current | 16A |
| Poles | 2 |
| Switching Capacity | 10kA |
| Series | BOLF |
| Manufacturer | Schrack |
| Packaging | 1 pcs., 60 pcs. |
