A residual current device (RCD) with integrated circuit breaker designed to protect electrical circuits from leakage currents and overloads. The device provides reliable protection of people from electric shock hazards and equipment from damage.
Main technical parameters:
- Rated current: 32 A
- Pole configuration: 1+N (single-phase + neutral)
- Rated sensitivity IΔn: 30 mA
- Switching capacity: 6 kA
- Trip characteristic: Instantaneous
- Characteristic type: C (sensitive to pulsating DC current)
- Protection type: A (trips on sinusoidal and pulsating leakage currents)
Operating conditions:
- Ambient temperature range: -35°C to +60°C
- Power loss: 6.60 W
Normative and technical basis:
The device complies with standards EN 61009-1:2012 + A12:2006 and EN 61009-2-1:1994 + A11:1998, which ensures its safety and reliability during operation.
Physical dimensions and weight:
- Length: 75.10 mm
- Width: 35.00 mm
- Height: 80.00 mm
- Net weight: 0.25 kg
Manufacturer and series: Schrack, BOLF series. EAN code: 9004840506709
Packaging options: 1 piece or 60 pieces.
| EAN code | 9004840506709 |
|---|---|
| Net length | 75.10 mm |
| Net width | 35.00 mm |
| Net height | 80.00 mm |
| Net weight | 0.25 kg |
| Power loss | 6.60 W |
| Min. ambient temperature | -35°C |
| Max. ambient temperature | 60°C |
| Standard | EN 61009-1:2012 + A12:2006, EN 61009-2-1:1994 + A11:1998 |
| Type | A (sensitive to pulsating current) |
| Type | Instantaneous |
| Rated sensitivity IΔn | 30 mA |
| Characteristic | C |
| Current rating | 32 A |
| Poles | 1+N |
| Switching capacity | 6 kA |
| Series | BOLF |
| Manufacturer | Schrack |
| Packaging | 1 piece, 60 pieces |
