Motor Protection Switch 1.0-1.6A/3 BE5
Article: BE501600--
26 160 ₸
In stock
Motor protection switch designed for protecting electric motors and circuits against overload and short circuit. The device provides reliable disconnection when the rated current is exceeded and operates in emergency operating conditions.
Main parameters:
- Current range: 1.0-1.6 A
- Rated breaking capacity: 100 kA
- Power loss: 6.0 W
- Temperature range: from -25°C to +55°C
- Size: BE5 (DIN rail)
- Overall dimensions: 45 × 93 × 76 mm
- Weight: 0.30 kg
The device is designed for installation on a standard 35 mm DIN rail and is compatible with distribution boards and electrical panels. Manufacturer: Schrack.
| EAN code | 9004840256192 |
|---|---|
| Net width | 45.00 mm |
| Net height | 93.00 mm |
| Net depth | 76.00 mm |
| Net weight | 0.30 kg |
| Power loss | 6.00 W |
| Min. ambient temperature | -25°C |
| Max. ambient temperature | 55°C |
| Current range | 1.0-1.6 A |
| Rated short circuit breaking capacity | 100 kA |
| Type | Motor protection switch |
| Size | BE5 |
| Manufacturer | Schrack |
| Packaging | 1 pc., 70 pc. |
