Automatic Circuit Breaker BM B20/3, 10kA
Article: BM018320--
25 850 ₸
To order
A three-pole automatic circuit breaker of the BMS0 series designed to protect electrical circuits from overloads and short circuits. The device is characterized by rated current of 20A, breaking capacity of 10kA, and Type B characteristic, providing tripping at currents 3–5 times the rated value.
Technical Parameters:
- Number of poles: 3
- Rated current: 20A
- Breaking capacity: 10kA
- Trip characteristic: B
- Execution: AC-MCB (alternating current)
- Power loss: 9.80W
- Operating temperature range: –40°C to +75°C
Dimensional Specifications:
- Width: 53.40 mm
- Height: 83.00 mm
- Depth: 74.90 mm
- Weight: 0.37 kg
Normative and Technical Standards:
The device complies with international standards EN 60898-1:2019, EN 60947-2:2006 + A1:2009 + A2:2013, EN 60947-2:2017 + A1:2020, EN 63000:2018.
Manufacturer: Schrack
EAN Code: 9004840393019
Packaging options: 1 pcs, 4 pcs, 40 pcs.
| EAN Code | 9004840393019 |
|---|---|
| Width (net) | 53.40 mm |
| Height (net) | 83.00 mm |
| Depth (net) | 74.90 mm |
| Weight (net) | 0.37 kg |
| Power loss | 9.80 W |
| Min. ambient temperature | –40°C |
| Max. ambient temperature | 75°C |
| Characteristic | B |
| Number of poles | 3 |
| Rated current | 20 A |
| Type | BMS0 |
| Series | BMS0 |
| Breaking capacity | 10 kA |
| Execution | AC-MCB |
| Standard | EN 60898-1:2019, EN 60947-2:2006 + A1:2009 + A2:2013, EN 60947-2:2017 + A1:2020, EN 63000:2018 |
| Manufacturer | Schrack |
| Packaging | 1 pcs, 4 pcs, 40 pcs |
