Automatic Circuit Breaker BM C2/2, 6kA

Automatic Circuit Breaker BM C2/2, 6kA

Article: BM617202--

Автоматические выключатели BM

12 670 ₸

In stock
WhatsAppTelegram

Two-pole automatic circuit breaker of the BMS6 series with a rated current of 2A and breaking capacity of 6kA. Designed to protect AC electrical circuits from overloads and short-circuit currents.

Main Parameters:

  • Trip Characteristic: C (trips at 5-10In current)
  • Number of Poles: 2
  • Rated Current: 2A
  • Breaking Capacity: 6kA
  • Design: AC-MCB (alternating current)
  • Power Loss: 2.80W
  • Operating Temperature Range: -40°C to +75°C

Dimensions and Weight:

  • Width: 35.60 mm
  • Height: 83.00 mm
  • Depth: 74.90 mm
  • Net Weight: 0.24 kg

Standards Compliance: EN 60898-1:2019, EN 60947-2:2006 + A1:2009 + A2:2013, EN 60947-2:2017 + A1:2020, EN 63000:2018

Manufacturer: Schrack

Packaging Options: 1 pcs., 6 pcs., 60 pcs.

EAN Code9004840396829
Net Width35.60 mm
Net Height83.00 mm
Net Depth74.90 mm
Net Weight0.24 kg
Power Loss2.80 W
Min. Ambient Temperature-40°C
Max. Ambient Temperature75°C
CharacteristicC
Poles2
Rated Current2 A
TypeBMS6
SeriesBMS6
Breaking Capacity6 kA
DesignAC-MCB
StandardEN 60898-1:2019, EN 60947-2:2006 + A1:2009 + A2:2013, EN 60947-2:2017 + A1:2020, EN 63000:2018
ManufacturerSchrack
Packaging1 pcs., 6 pcs., 60 pcs.

Optional accessories (3)
