Residual current device (RCD) designed to protect electrical circuits from leakage currents and overloads. The device provides reliable protection of personnel from electric shock under direct and indirect contact conditions.
Main parameters:
- Nominal current: 16 A
- Configuration: 1 phase + neutral (1+N)
- Rated differential current sensitivity (IΔn): 30 mA
- Trip type: A — sensitive to sinusoidal alternating and pulsating direct current
- Characteristic: C (tripping curve for circuits with inductive loads)
- Switching capacity: 6 kA
- Trip mode: instantaneous
Technical specifications:
- Operating temperature range: from −35°C to +60°C
- Power loss: 3.2 W
- Overall dimensions: 75.10 × 35.00 × 80.00 mm
- Weight: 0.25 kg
- Standards compliance: EN 61009-1:2012 + A12:2006, EN 61009-2-1:1994 + A11:1998
Manufacturer: Schrack, BOLF series
Package contents: 1 pc.
| EAN code | 9004840506679 |
|---|---|
| Length (net) | 75.10 mm |
| Width (net) | 35.00 mm |
| Height (net) | 80.00 mm |
| Weight (net) | 0.25 kg |
| Power loss | 3.20 W |
| Min. ambient temperature | −35°C |
| Max. ambient temperature | 60°C |
| Standard | EN 61009-1:2012 + A12:2006, EN 61009-2-1:1994 + A11:1998 |
| Type (current sensitivity) | A (sensitive to pulsating current) |
| Type (trip mode) | instantaneous |
| Rated sensitivity IΔn | 30 mA |
| Characteristic | C |
| Rated current | 16 A |
| Poles | 1+N |
| Switching capacity | 6 kA |
| Series | BOLF |
| Manufacturer | Schrack |
| Package | 1 pc. |
