Contactor 7.5kW/400V/15.5A/1NC, coil 230VAC
Article: LTD01523--
22 120 ₸
To order
Industrial contactor designed for switching three-phase AC circuits in electrical control and protection systems. The contactor provides reliable switching of electric motors and other electrical equipment with power ratings up to 7.5 kW at 400 V mains voltage.
Main characteristics:
- Rated mains voltage: 400 V AC (3~)
- Rated current: 15.5 A
- Power (AC-3, 380/400 V): 7.5 kW
- Coil control voltage: 230 V AC
- Main contacts: 3 normally open contacts (3NO)
- Auxiliary contacts: 1 normally closed contact (1NC)
- Power loss: 3.90 W
- Manufacturer: Schrack (quality European equipment)
Dimensions and weight:
- Width: 45 mm
- Height: 68 mm
- Depth: 75 mm
- Net weight: 0.24 kg
- EAN-code: 9004840841220
Packaging: supplied in single unit packaging (1 pc.) and box packaging (102 pcs.)
The contactor is mounted on standard DIN rail and is used in automation systems, motor control systems, and for switching compressors, pumps, and other industrial equipment.
| EAN-code | 9004840841220 |
|---|---|
| Width net | 45.00 mm |
| Height net | 68.00 mm |
| Depth net | 75.00 mm |
| Net weight | 0.24 kg |
| Power loss | 3.90 W |
| Size | 0 |
| Type | Industrial contactor |
| Auxiliary contacts included | 1 normally closed contact |
| AC coil voltage | 230 V AC |
| Rated current | 15.50 A |
| Main contacts | 3 normally open contacts |
| Manufacturer | Schrack |
| AC-3 380 V 400 V [P] | 7.5 kW |
| Packaging | 1 pc., 102 pcs. |
