Motor Protection Breaker 16.0-25.0A/2 BE4
Article: BE400212--
18 840 ₸
To order
Motor protection breaker designed to protect electric motors against overload and short circuit conditions. The device provides reliable operation across a wide temperature range and complies with international safety standards.
Main Parameters:
- Rated Current: 16.0–25.0 A
- Execution: 2-pole
- Operating Temperature Range: –40 °C to +70 °C
- Power Loss: 8.30 W
- Dimensions (H×W×D): 82×37×73 mm
- Weight: 0.23 kg
- Standard: EN 60947-2:2006 + A1:2009 + A2:2013
- Manufacturer: Schrack
- EAN Code: 9004840266160
The breaker ensures reliable protection of electrical equipment in industrial and commercial installations.
| EAN Code | 9004840266160 |
|---|---|
| Net Length | 73.00 mm |
| Net Width | 37.00 mm |
| Net Height | 82.00 mm |
| Net Weight | 0.23 kg |
| Power Loss | 8.30 W |
| Min. Ambient Temperature | -40 °C |
| Max. Ambient Temperature | 70 °C |
| Execution | 2 |
| Current Rating | 16-25 A |
| Standard | EN 60947-2:2006 + A1:2009 + A2:2013 |
| Manufacturer | Schrack |
| Packaging | 1 pcs., 6 pcs. |
