Motor Protection Switch 0.25-0.40A/3 BE4
Article: BE400303--
28 560 ₸
In stock
Motor protection switch is designed to protect electric motors and other electrical devices from overload and short circuit. The device has a nominal current rating of 0.25-0.40 A and complies with the European standard EN 60947-2:2006 + A1:2009 + A2:2013.
Technical parameters:
- Nominal current: 0.25-0.40 A
- Design: 3-pole
- Power loss: 5.80 W
- Operating temperature range: -40°C to +70°C
- Dimensions (W×H×D): 53.40 × 80.00 × 71.00 mm
- Weight: 0.34 kg
- Manufacturer: Schrack
- Standard: EN 60947-2:2006 + A1:2009 + A2:2013
The device is supplied in packages of 1 or 4 units and is designed for mounting on DIN-rail in distribution boards and control cabinets.
| EAN Code | 9004840266207 |
|---|---|
| Net Width | 53.40 mm |
| Net Height | 80.00 mm |
| Net Depth | 71.00 mm |
| Net Weight | 0.34 kg |
| Power Loss | 5.80 W |
| Min. Ambient Temperature | -40°C |
| Max. Ambient Temperature | 70°C |
| Design | 3-pole |
| Current Rating | 0.25-0.40 A |
| Standard | EN 60947-2:2006 + A1:2009 + A2:2013 |
| Manufacturer | Schrack |
| Packaging | 1 unit, 4 units |
