Automatic Circuit Breaker BM B6/2, 6kA
Article: BM618206--
8 065 ₸
In stock
Automatic Circuit Breaker BM B6/2 is designed to protect electrical circuits from short-circuit and overload currents. A two-pole device with a nominal current of 6 A and breaking capacity of 6 kA that meets the B trip characteristic (tripping at 3–5 times the rated current).
Key Parameters:
- Nominal Current: 6 A
- Number of Poles: 2
- Breaking Capacity: 6 kA
- Trip Characteristic: B
- Type: AC-MCB (Modular Automatic Circuit Breaker for alternating current)
- Power Loss: 3.60 W
- Operating Temperature Range: from –40 °C to +75 °C
- Physical Dimensions: 35.60 × 83.00 × 74.90 mm (width × height × depth)
- Net Weight: 0.24 kg
Applicable Standards:
Complies with the requirements of EN 60898-1:2019, EN 60947-2:2006 + A1:2009 + A2:2013, EN 60947-2:2017 + A1:2020, EN 63000:2018.
Manufacturer: Schrack. Available Packaging Options: 1 pc., 6 pcs., 60 pcs.
| EAN Code | 9004840396225 |
|---|---|
| Width (Net) | 35.60 mm |
| Height (Net) | 83.00 mm |
| Depth (Net) | 74.90 mm |
| Net Weight | 0.24 kg |
| Power Loss | 3.60 W |
| Min. Ambient Temperature | –40 °C |
| Max. Ambient Temperature | 75 °C |
| Characteristic | B |
| Poles | 2 |
| Nominal Current | 6 A |
| Type | BMS6 |
| Series | BMS6 |
| Breaking Capacity | 6 kA |
| Design | AC-MCB |
| Standard | EN 60898-1:2019, EN 60947-2:2006 + A1:2009 + A2:2013, EN 60947-2:2017 + A1:2020, EN 63000:2018 |
| Manufacturer | Schrack |
| Packaging | 1 pc., 6 pcs., 60 pcs. |
