Motor Protection Automatic Switch 0.16-0.25A/2 BE4
Article: BE400202--
18 840 ₸
In stock
The BE4 series motor protection automatic switch is designed to protect electric motors from overload and short circuits. The device ensures reliable disconnection when the set current is exceeded.
Technical Parameters:
- Current trip range: 0.16–0.25 A
- Configuration: 2-pole
- Standard: EN 60947-2:2006 + A1:2009 + A2:2013
- Power loss: 5.30 W
- Temperature range: –40 °C to +70 °C
Dimensions:
- Length: 73 mm
- Width: 37 mm
- Height: 82 mm
- Weight: 0.23 kg
Manufacturer: Schrack (Austria)
Packaging options: 1 pcs, 6 pcs, 60 pcs
The device complies with international quality and reliability standards and is used in industrial and power supply networks for protection of low-power motors.
| EAN code | 9004840266061 |
|---|---|
| Length (net) | 73.00 mm |
| Width (net) | 37.00 mm |
| Height (net) | 82.00 mm |
| Weight (net) | 0.23 kg |
| Power loss | 5.30 W |
| Min. ambient temperature | –40 °C |
| Max. ambient temperature | 70 °C |
| Configuration | 2-pole |
| Current rating | 0.16–0.25 A |
| Standard | EN 60947-2:2006 + A1:2009 + A2:2013 |
| Manufacturer | Schrack |
| Packaging | 1 pcs, 6 pcs, 60 pcs |
